Electron Microscopy Services
SEM imaging
Scanning Electron Microscopy (SEM) is a high-resolution imaging technique that utilizes a focused electron beam to scan the surface of a sample, generating detailed images of its topography and composition. SEM is capable of revealing features down to the nanometer scale, making it an ideal method for analyzing microstructures, thin films
Scanning Electron Microscopy (SEM) is a high-resolution imaging technique that utilizes a focused electron beam to scan the surface of a sample, generating detailed images of its topography and composition. SEM is capable of revealing features down to the nanometer scale, making it an ideal method for analyzing microstructures, thin films, and materials used in research and semiconductor fabrication. Additionally, it offers a depth of field and contrast that far surpasses optical microscopes, enabling precise inspection of surface morphology and defects.
